Aka Marine R52-B / Orange

Overview

RIB-B Series

As a true Swiss Army knife, the RIB-B Series (PVC or CSM-CR) is the perfect multi-purpose range with a heavy duty bow fender design.

It can access remote location thanks to its 75L built-in fuel tank.

Colors

Plastomer 2*1100 dtx or CSM-CR 1670 dtx Black

Plastomer 2*1100 dtx or CSM-CR 1670 dtx Medium grey

Plastomer 2*1100 dtx Red

CSM-CR 1670 dtx Orange

Key features

  • Multi-purpose RIB
  • Removable slide-on tubes
  • Choice of tubes : Plastomer 2*1100 dtx (Thermo welding technology) or CSM-CR 1670 dtx (Chlorosulfonated Polyethylene – Neoprene)
  • Heavy Duty bow fender design
  • 75 L built-in fuel tank (R52-B)
Specifications
Model
R52-B
Category Name
Boat
Year
2022
Sale Type
New
Manufacturer
Aka Marine
recommended for

Law enforcement

  • Patrol
  • Coast Guard
  • Police
  • Administration / Authorities

Professional

  • Marina, port activities
  • Expeditions
  • Hotels & resorts
  • Clubs

Search & rescue

  • First responders
  • Fire brigades
  • Surveillance

Military

  • Army
  • Navy
dimensions
Inside_width
1,2 - 3'11''
Inside_length
4,02 - 13'2''
Overall_width
2,2 - 7'3''
Overall_length
5,2 - 17'2''
Buoyancy_tube_diameter
0,5 - 1'8''
capacity
Airtight_compartments
5
Passengers_(ISO_Cat._C)
12
Total_weight_(kg_-_lbs)
315 - 694
Maximum_payload_(kg_-_lbs)_Cat_C
1390 - 3064
design category
European_directive_N°_2013/53/_EU
C
outboard data
Shaft
Long
Max._power_allowed_(Hp)
50
Max._power_allowed_(kW)
37
Max._speed_(km/h_-_mph)
68 - 42
Max._recommended_power_(Hp)
70
Max._recommended_power_(kW)
53
Min._recommended_power_(Hp)
40
Min._recommended_power_(kW)
30
Max._weight_of_outboard_(kg_-_lbs)
200 - 441
hull storage dimensions
Width
1,53 - 5'0''
Height
0,81 - 2'8''
Length
4,46 - 14'8''
Hull_angle
24,5°
features

Buoyancy tube

  • CSM-CR 1670 dtx fabric (Thermo welding technology)
  • Removable tube system
  • Anti-skid patches
  • Heavy Duty, anti-chafing, bow fender system
  • Polyester internal / external Grab line
  • Leafield inflation valves
  • Leafield pressure relief valves
  • Large profile rubbing strake
  • 4 external handles
  • Reinforced cone ends

Hull

  • Fibreglass deep V-shaped hull
  • Moulded non-skid deck
  • Bow locker
  • 1 Bow D-ring
  • 2 Towing rings
  • 1 Aluminum engine support plate
  • 2 High volume self-bailer
  • 1 Mooring bollard
  • 4 Lifting points

Standard equipment

  • Built-in fuel tank (75litres) + fuel/water separator
  • Removable storage box
  • 2 paddles
  • Foot pump & pressure gauge
  • Repair kit
  • Owner’s manual

Optional Accessories

  • GRP Console standard
  • GRP Console Large
  • GRP Bolster seat
  • Single stainless steel bolster
  • Jockey seat
  • Roll-bar
  • T-TOP
  • Bow rail
  • PVC keel protection
  • Diving cylinders holder
